incl. IVA più costi di spedizione
Seleziona una variante per andare avanti
- Articolo n°: T1295590101
Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio 6061, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn 3
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 50
- Forcella: RockShox 35 Silver, Molla in acciaio, 160mm
- Ammortizzatore: RockShox Deluxe Select, Aria
- Serie sterzo: A-Head Tapered
- Travel front: 160
- Travel rear: 160
Gear shift and brakes
- Cambio: Sram SX Eagle 12-S, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram PG1210 11-50T
- Catena: Sram SX Eagle
- Brakes: Shimano MT420, Alluminio, 203mm / 203mm
- Leva del freno: Shimano MT401, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX GEN4, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch compact charger 2A
- Batteria: Bosch PowerTube 625Wh
- Battery capacity: 625
- Display: Bosch Purion
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 65-622 / Maxxis Minion DHR II, 71-584
- Cerchio: Rodi Tryp 30, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Leader
- Dimensione ruota: 29/27.5
- Wheelhub: Shimano MT400-B, Shimano MT400-B
Handlebar and saddle
- Sella: XLC MTB
- Reggisella: dropper-post remote, Telescopico, 31.6 mm, Alluminio
- Manubrio: Haibike Components TheBar ++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Alluminio, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 567, 588, 654
- Seat tube length: 410, 440, 500
- Seat tube angle: 75
- Head tube length: 115, 120, 145
- Head tube angle: 65
- Chain stay length: 455
- Bottom bracket drop: -20
- Wheelbase: 1194, 1216, 1287
- Reach: 410, 430, 490
- Stack: 639, 643, 666
- Seat tube offset: 15
- Stand-over height: 81, 82, 84
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 160mm
- Frame shape: MTB Fully
- Model name: ALLMTN 3
- Peso totale consentito: 135
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox 35 Gold RL, Aria, 160mm
- Ammortizzatore: RockShox Deluxe Select, Aria
- Serie sterzo: Acros BlockLock
- Travel front: 160
- Travel rear: 160
Gear shift and brakes
- Cambio: Shimano Deore M6100 12-S, 12 velocità, Deore M6100, Comando Trigger
- Pacco pignoni : Shimano M6100
- Catena: Shimano M6100
- Brakes: Shimano MT420, Alluminio, 203mm / 203mm
- Leva del freno: Shimano MT401, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584
- Cerchio: WTB ST i30 TCS, Con occhielli, Cerchio a camera vuota
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 29/27.5
- Wheelhub: Shimano MT400-B, Shimano MT410-B
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem ++, A-head, Handlebar diameter: 31.8 mm
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3899,00 [pseudoprice] => 5599,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 3899 [pseudoprice_numeric] => 5599 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 16923 [position] => [source] => https://www.sportgardena.com/media/image/4c/0d/63/allmtn-3-grey.jpg [description] => [extension] => jpg [main] => [parentId] => [width] => 1289 [height] => 716 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/8a/f1/8f/allmtn-3-grey_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/45/ae/93/allmtn-3-grey_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/8a/f1/8f/allmtn-3-grey_200x200.jpg, https://www.sportgardena.com/media/image/45/ae/93/allmtn-3-grey_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/22/73/c5/allmtn-3-grey_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/3c/0f/89/allmtn-3-grey_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/22/73/c5/allmtn-3-grey_600x600.jpg, https://www.sportgardena.com/media/image/3c/0f/89/allmtn-3-grey_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/77/3b/2b/allmtn-3-grey_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/b1/41/f6/allmtn-3-grey_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/77/3b/2b/allmtn-3-grey_1280x1280.jpg, https://www.sportgardena.com/media/image/b1/41/f6/allmtn-3-grey_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 9122 [imageID] => 139310 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3899,00 [pseudoprice] => 5599,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 30 [float] => 30.36 ) [has_pseudoprice] => 1 [price_numeric] => 3899 [pseudoprice_numeric] => 5599 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1634380201 [linkDetails] => shopware.php?sViewport=detail&sArticle=3131 [linkVariant] => shopware.php?sViewport=detail&sArticle=3131&number=T1634380201 ) 1Haibike AllMtn 3 (2023) usata in top condizioni da vendere.
Specification
Frame and more
- Brand: Haibike
- Frame: Haibike Aluminium 6061, Tapered Head Tube, Integrated Motor, Skidplate, 29", 160Mm
- permitted total weight: 120
- Fork: Rockshox Yari Rc, Air, 160Mm
- Damper: Rockshox Deluxe Select Plus, Air
- Bottom bracket: 2
- Head set: A-head Tapered
- Model name: Allmtn 3
- Travel front: 160
Gear shift and brakes
- Gearshift: Sram Sx Eagle, 12 Gears, Sx Eagle, Trigger Switch
- Sprocket: Sram Eagle Pg1210, 11-50 Teeth
- Chain: Sram Sx Eagle
- Number of gears: 12
- Brakes: Shimano Mt420, Aluminium, 203Mm / Shimano Mt420, Aluminium, 203Mm
- Brake lever: Shimano Mt401, Aluminium
- Chain guide: Nylon Directmount
- Crank arm: Haibike Components The Crank ++
- Type of brake: 4-Piston Disc Brake
Handlebar and saddle
- Saddle: Selle Royal Vivo
- Seat post: Haibike Components Theseatpost ++, 31.6 Mm, Aluminium
- Handlebar: Haibike Components Thebar +++ Gravity, 780 Mm
- Grips: Haibike Mtb Grips
- Stem: Haibike Components Thestem 2, A-head, Bar Bore: 31.8 Mm
Propulsion
- Engine: Bosch Performance Cx Gen4, 250W, 25Km/h, 85Nm
- Charger: Bosch
- Display: Bosch Purion
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Tyres: Maxxis Minion Dhf Ii, 65-622 / Maxxis Minion Dhr Ii, 71-584
- Rim: Rodi Tryp 30, Eyed, Double-walled Rim, Aluminium
- Tube: Presta Valve
- Spokes: Sapim Leader, Black
- Wheelhub: Shimano Mt400-b, Shimano Mt400-b
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3119,35 [pseudoprice] => 4799,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 3119.35 [pseudoprice_numeric] => 4799 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 8485 [position] => [source] => https://www.sportgardena.com/media/image/f4/6a/e4/ALLMTN-3-b.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1206 [height] => 661 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/a0/c7/b3/ALLMTN-3-b_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/4c/0d/e3/ALLMTN-3-b_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/a0/c7/b3/ALLMTN-3-b_200x200.jpg, https://www.sportgardena.com/media/image/4c/0d/e3/ALLMTN-3-b_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/b2/96/83/ALLMTN-3-b_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/b8/8a/14/ALLMTN-3-b_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/b2/96/83/ALLMTN-3-b_600x600.jpg, https://www.sportgardena.com/media/image/b8/8a/14/ALLMTN-3-b_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/dc/93/f3/ALLMTN-3-b_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/96/d6/ce/ALLMTN-3-b_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/dc/93/f3/ALLMTN-3-b_1280x1280.jpg, https://www.sportgardena.com/media/image/96/d6/ce/ALLMTN-3-b_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 4984 [imageID] => 98976 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3119,35 [pseudoprice] => 4799,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 35 [float] => 35 ) [has_pseudoprice] => 1 [price_numeric] => 3119.35 [pseudoprice_numeric] => 4799 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=SG10450.1 [linkDetails] => shopware.php?sViewport=detail&sArticle=2514 [linkVariant] => shopware.php?sViewport=detail&sArticle=2514&number=SG10450.1 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn 2
- Peso totale consentito: 135
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox 35 Gold RL, Aria, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: Acros BlockLock
- Travel front: 160
- Travel rear: 140, 160
Gear shift and brakes
- Cambio: Sram SX Eagle 12-S, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram PG1210 11-50T
- Catena: Sram SX Eagle
- Brakes: Sram DB8, Alluminio
- Leva del freno: Sram DB8, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584
- Cerchio: WTB ST i30 TCS, Con occhielli, Cerchio a camera vuota
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 29/27.5
- Wheelhub: Haibike Components The Hub ++ through axle 15x110mm, Haibike Components TheHub ++ Steckachse 12x148
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem +++
Geometry
- Top tube length (horizontal): 570, 600, 615, 659
- Seat tube length: 410, 440, 465, 495
- Seat tube angle: 75
- Head tube length: 120, 130, 140
- Head tube angle: 64.5, 65
- Chain stay length: 460
- Bottom bracket drop: -20
- Wheelbase: 1220, 1250, 1259, 1313
- Reach: 421, 451, 475, 505
- Stack: 610, 646, 664
- Seat tube offset: 23
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3499,00 [pseudoprice] => 5399,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 3499 [pseudoprice_numeric] => 5399 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11112 [position] => [source] => https://www.sportgardena.com/media/image/04/ab/ba/allmtn-2-green.jpg [description] => [extension] => jpg [main] => [parentId] => [width] => 1206 [height] => 676 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/08/10/1f/allmtn-2-green_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/cd/fc/10/allmtn-2-green_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/08/10/1f/allmtn-2-green_200x200.jpg, https://www.sportgardena.com/media/image/cd/fc/10/allmtn-2-green_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/70/89/de/allmtn-2-green_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/a9/77/5a/allmtn-2-green_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/70/89/de/allmtn-2-green_600x600.jpg, https://www.sportgardena.com/media/image/a9/77/5a/allmtn-2-green_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/c3/e0/31/allmtn-2-green_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/b2/d3/3e/allmtn-2-green_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/c3/e0/31/allmtn-2-green_1280x1280.jpg, https://www.sportgardena.com/media/image/b2/d3/3e/allmtn-2-green_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5971 [imageID] => 109349 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3499,00 [pseudoprice] => 5399,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 35 [float] => 35.19 ) [has_pseudoprice] => 1 [price_numeric] => 3499 [pseudoprice_numeric] => 5399 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295500301 [linkDetails] => shopware.php?sViewport=detail&sArticle=2237 [linkVariant] => shopware.php?sViewport=detail&sArticle=2237&number=T1295500301 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29.0", 150mm
- Frame shape: MTB Fully
- Model name: ALLTRAIL 10 29.0
- Peso totale consentito: 150
- Frame height:
- · 41
- · 44
- · 47
- Forcella: RockShox 35 Gold RL, Aria, 150mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: A-Head Tapered
- Travel front: 150
- Travel rear: 150
Gear shift and brakes
- Cambio: Sram GX Eagle Transmission 12-S, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram PG1210 11-50T
- Catena: Sram SX Eagle
- Brakes: Shimano MT420, Alluminio, 203mm / 203mm
- Leva del freno: Shimano MT401, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX Smart System, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch
- Batteria: Bosch PowerTube 750Wh
- Battery capacity: 750
- Display: Bosch Kiox 300 + LED Remote
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Schwalbe Magic Mary Evo TLE, 65-584 / Schwalbe Hans Dampf Evo TLE, 65-584
- Cerchio: Rodi Tryp 30, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 27.5
- Wheelhub: aluminum hub, aluminum hub
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar ++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: aluminum, A-head
Geometry
- Top tube length (horizontal): 573, 589, 605
- Seat tube length: 410, 440, 470
- Seat tube angle: 75
- Head tube length: 140, 145
- Head tube angle: 65
- Chain stay length: 455
- Bottom bracket drop: -20
- Wheelbase: 1205, 1222, 1239
- Reach: 420, 435, 450
- Stack: 629, 633, 638
- Seat tube offset: 15
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2749,00 [pseudoprice] => 4999,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2749 [pseudoprice_numeric] => 4999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 21129 [position] => [source] => https://www.sportgardena.com/media/image/d0/b3/ea/Haibike_MY22_ALLTRACK_10_29.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1370 [height] => 764 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/a6/aa/c6/Haibike_MY22_ALLTRACK_10_29_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/8d/9a/e1/Haibike_MY22_ALLTRACK_10_29_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/a6/aa/c6/Haibike_MY22_ALLTRACK_10_29_200x200.jpg, https://www.sportgardena.com/media/image/8d/9a/e1/Haibike_MY22_ALLTRACK_10_29_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/3a/20/50/Haibike_MY22_ALLTRACK_10_29_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/99/c7/e7/Haibike_MY22_ALLTRACK_10_29_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/3a/20/50/Haibike_MY22_ALLTRACK_10_29_600x600.jpg, https://www.sportgardena.com/media/image/99/c7/e7/Haibike_MY22_ALLTRACK_10_29_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/37/cd/e9/Haibike_MY22_ALLTRACK_10_29_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/13/f1/3b/Haibike_MY22_ALLTRACK_10_29_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/37/cd/e9/Haibike_MY22_ALLTRACK_10_29_1280x1280.jpg, https://www.sportgardena.com/media/image/13/f1/3b/Haibike_MY22_ALLTRACK_10_29_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( ) [attribute] => Array ( ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2749,00 [pseudoprice] => 4999,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 45 [float] => 45.01 ) [has_pseudoprice] => 1 [price_numeric] => 2749 [pseudoprice_numeric] => 4999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1710750201 [linkDetails] => shopware.php?sViewport=detail&sArticle=3578 [linkVariant] => shopware.php?sViewport=detail&sArticle=3578&number=T1710750201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 27.5"
- Frame shape: 66_6
- Model name: AllTrack 5 27.5
- Peso totale consentito: 120
- Frame height: 45
- Forcella: SR Suntour XCM32 Boost DS, 120mm
- Serie sterzo: A-Head Tapered
- Travel front: 120
Gear shift and brakes
- Cambio: Microshift Advent X RD-M6205M, 10 velocità, Advent X SL-M9505-R, Comando Trigger
- Pacco pignoni : Microshift Advent X HG104, 11-48 denti
- Catena: KMC e10S
- Brakes: Shimano MT200 180mm, Alluminio
- Leva del freno: Shimano MT201, Alluminio
- Crank arm: Miranda Kies
Propulsion
- Motore: Yamaha PW-S2, 250W, 25km/h, 75Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 75
Wheels and wheel components
- Copertone: Schwalbe Nobby Nic Performance, 65-584
- Cerchio: Rodi Tryp 30, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Leader
- Dimensione ruota: 27.5
- Wheelhub: Shimano MT400-B, Alu Nabe
Handlebar and saddle
- Sella: XLC MTB
- Reggisella: Patent, 34.9 mm, Alluminio
- Manubrio: XLC, 720 mm
- Manopole: XLC Manopole MTB
- Attacco manubrio: XLC A-head, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 620
- Seat tube length: 450
- Seat tube angle: 74
- Head tube length: 140
- Head tube angle: 68
- Chain stay length: 465
- Bottom bracket drop: -60
- Wheelbase: 1181
- Reach: 432
- Stack: 656
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2449,00 [pseudoprice] => 3299,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2449 [pseudoprice_numeric] => 3299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 19485 [position] => [source] => https://www.sportgardena.com/media/image/g0/d4/f1/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1373 [height] => 791 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/15/60/4d/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/80/03/g0/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/15/60/4d/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_200x200.jpg, https://www.sportgardena.com/media/image/80/03/g0/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/c4/5e/c1/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/2c/0f/a0/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/c4/5e/c1/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_600x600.jpg, https://www.sportgardena.com/media/image/2c/0f/a0/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/9a/fe/c4/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/a4/08/75/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/9a/fe/c4/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_1280x1280.jpg, https://www.sportgardena.com/media/image/a4/08/75/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 10626 [imageID] => 152045 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2449,00 [pseudoprice] => 3299,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 26 [float] => 25.77 ) [has_pseudoprice] => 1 [price_numeric] => 2449 [pseudoprice_numeric] => 3299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T3B2RN30301 [linkDetails] => shopware.php?sViewport=detail&sArticle=3355 [linkVariant] => shopware.php?sViewport=detail&sArticle=3355&number=T3B2RN30301 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29"
- Frame shape: 66_6
- Model name: AllTrack 5 29
- Peso totale consentito: 120
- Frame height:
- · 45
- · 50
- · 55
- Forcella: SR Suntour XCM32 Boost DS, 120mm
- Serie sterzo: A-Head Tapered
- Travel front: 120
Gear shift and brakes
- Cambio: Microshift Advent X RD-M6205M, 10 velocità, Advent X SL-M9505-R, Comando Trigger
- Pacco pignoni : Microshift Advent X HG104, 11-48 denti
- Catena: KMC e10S
- Brakes: Shimano MT200 180mm, Alluminio
- Leva del freno: Shimano MT201, Alluminio
- Crank arm: Miranda Kies
Propulsion
- Motore: Yamaha PW-S2, 250W, 25km/h, 75Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 75
Wheels and wheel components
- Copertone: Schwalbe Nobby Nic Performance, 65-622
- Cerchio: Rodi Tryp 30, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Leader
- Dimensione ruota: 29
- Wheelhub: Shimano MT400-B, Alu Nabe
Handlebar and saddle
- Sella: XLC MTB
- Reggisella: Patent, 34.9 mm, Alluminio
- Manubrio: XLC, 720 mm
- Manopole: XLC Manopole MTB
- Attacco manubrio: XLC A-head, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 625, 648, 670
- Seat tube length: 450, 500, 550
- Seat tube angle: 74
- Head tube length: 140, 155, 170
- Head tube angle: 67
- Chain stay length: 475
- Bottom bracket drop: -65
- Wheelbase: 1216, 1240, 1264
- Reach: 432, 452, 472
- Stack: 674, 683, 692
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2449,00 [pseudoprice] => 3299,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2449 [pseudoprice_numeric] => 3299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 19486 [position] => [source] => https://www.sportgardena.com/media/image/be/95/6a/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1375 [height] => 788 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/f5/29/17/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/7a/be/0d/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/f5/29/17/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_200x200.jpg, https://www.sportgardena.com/media/image/7a/be/0d/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/f8/c7/62/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/33/26/75/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/f8/c7/62/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_600x600.jpg, https://www.sportgardena.com/media/image/33/26/75/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/9b/1f/40/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/06/54/cc/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/9b/1f/40/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_1280x1280.jpg, https://www.sportgardena.com/media/image/06/54/cc/HAI_MY23_ALLTRACK_5_290_High_grey_slate_90-1_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 10627 [imageID] => 152048 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2449,00 [pseudoprice] => 3299,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 26 [float] => 25.77 ) [has_pseudoprice] => 1 [price_numeric] => 2449 [pseudoprice_numeric] => 3299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1658250201 [linkDetails] => shopware.php?sViewport=detail&sArticle=3354 [linkVariant] => shopware.php?sViewport=detail&sArticle=3354&number=T1658250201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 160mm
- Frame shape: MTB Fully
- Model name: ALLMTN 5
- Peso totale consentito: 150
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox Yari RC, Aria, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: A-Head Tapered
- Travel front: 160
- Travel rear: 160
Gear shift and brakes
- Cambio: Sram NX Eagle, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram PG1210 11-50T
- Catena: Sram SX Eagle
- Brakes: Shimano MT420, Alluminio, 203mm / 203mm
- Leva del freno: Shimano MT401, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX Smart System, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch
- Batteria: Bosch PowerTube 750Wh
- Battery capacity: 750
- Display: Bosch Kiox 300 + LED Remote
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584
- Cerchio: WTB ST i30 TCS, Con occhielli, Cerchio a camera vuota
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 29/27.5
- Wheelhub: aluminum hub, aluminum hub
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem ++, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 581, 605, 631, 658
- Seat tube length: 410, 440, 470, 500
- Seat tube angle: 75
- Head tube length: 120, 135, 145
- Head tube angle: 64.5
- Chain stay length: 455
- Bottom bracket drop: -20
- Wheelbase: 1218, 1242, 1269, 1297
- Reach: 420, 444, 469, 495
- Stack: 658, 662, 667
- Seat tube offset: 15
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4199,00 [pseudoprice] => 5599,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 4199 [pseudoprice_numeric] => 5599 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 19481 [position] => [source] => https://www.sportgardena.com/media/image/b4/c6/aa/Haibike_MY23_ALLMTN_5.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1289 [height] => 707 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/f1/95/a9/Haibike_MY23_ALLMTN_5_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/da/4e/bb/Haibike_MY23_ALLMTN_5_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/f1/95/a9/Haibike_MY23_ALLMTN_5_200x200.jpg, https://www.sportgardena.com/media/image/da/4e/bb/Haibike_MY23_ALLMTN_5_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/34/52/bc/Haibike_MY23_ALLMTN_5_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/c9/c8/a1/Haibike_MY23_ALLMTN_5_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/34/52/bc/Haibike_MY23_ALLMTN_5_600x600.jpg, https://www.sportgardena.com/media/image/c9/c8/a1/Haibike_MY23_ALLMTN_5_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/82/4a/68/Haibike_MY23_ALLMTN_5_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/70/91/fc/Haibike_MY23_ALLMTN_5_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/82/4a/68/Haibike_MY23_ALLMTN_5_1280x1280.jpg, https://www.sportgardena.com/media/image/70/91/fc/Haibike_MY23_ALLMTN_5_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 10624 [imageID] => 152035 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4199,00 [pseudoprice] => 5599,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 25 [float] => 25 ) [has_pseudoprice] => 1 [price_numeric] => 4199 [pseudoprice_numeric] => 5599 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1658210101 [linkDetails] => shopware.php?sViewport=detail&sArticle=3353 [linkVariant] => shopware.php?sViewport=detail&sArticle=3353&number=T1658210101 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Carbon/Aluminum, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn CF 11
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox Lyrik Ultimate RC, Aria/Olio, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: Acros Cable integration
- Travel front: 160
- Travel rear: 150, 160
Gear shift and brakes
- Cambio: Shimano Deore XT RD-M8100 12-S, 12 velocità, Deore SLX M7100
- Pacco pignoni : Shimano M6100
- Catena: Shimano M6100
- Brakes: Shimano SLX M7120, Alluminio, 203mm / 203mm
- Leva del freno: Shimano SLX M7100, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX Smart System, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch
- Batteria: Bosch PowerTube 750Wh
- Battery capacity: 750
- Display: Bosch Kiox 300 + LED Remote
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 65-622 / Maxxis Minion DHR II, 71-584
- Tube: Valvola Presta
- Dimensione ruota: 29/27.5
- Set di ruote: Mavic E- Deemax S
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: dropper-post remote, Telescopico, 31.6 mm, Alluminio
- Manubrio: Haibike Components TheBar ++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Alluminio, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 577, 606, 642, 676
- Seat tube length: 410, 440, 470, 500
- Seat tube angle: 76
- Head tube length: 100, 110, 120, 130
- Head tube angle: 64.1
- Chain stay length: 455
- Bottom bracket drop: 23
- Wheelbase: 1191, 1230, 1267, 1303
- Reach: 403, 435, 463, 496
- Stack: 629, 638, 647, 657
- Seat tube offset: 15
- Stand-over height: 79, 81, 83
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 6399,00 [pseudoprice] => 7999,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 6399 [pseudoprice_numeric] => 7999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 19484 [position] => [source] => https://www.sportgardena.com/media/image/9e/ca/3f/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1328 [height] => 740 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/7e/bc/6e/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/e9/e0/c8/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/7e/bc/6e/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_200x200.jpg, https://www.sportgardena.com/media/image/e9/e0/c8/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/ef/3f/c8/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/25/85/b3/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/ef/3f/c8/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_600x600.jpg, https://www.sportgardena.com/media/image/25/85/b3/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/d4/94/2e/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/f8/a8/45/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/d4/94/2e/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_1280x1280.jpg, https://www.sportgardena.com/media/image/f8/a8/45/HAI_MY23_ALLMTN_CF_11_slate_neon_yellow_90_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 10625 [imageID] => 152040 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 6399,00 [pseudoprice] => 7999,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 20 [float] => 20 ) [has_pseudoprice] => 1 [price_numeric] => 6399 [pseudoprice_numeric] => 7999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1658160201 [linkDetails] => shopware.php?sViewport=detail&sArticle=3352 [linkVariant] => shopware.php?sViewport=detail&sArticle=3352&number=T1658160201 ) 1Haibike AllMtn 2 usata in top condizioni da vendere
Specifiche
ENGINE
Yamaha, PW-X3, 250 W, 85 Nm
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY
InTube, 720 Wh
FRAME FAMILY
Haibike, AllMtn PW-X3, Aluminium
FORK
RockShox, 35 Gold RL, Air, 160 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
DAMPER
RockShox, Deluxe Select Plus, Air, Trunnion Mount
CRANK ARM
Haibike Components, The Crank ++, Aluminium
BRAKE (FRONT)
TRP, Slate T4, Hydraulic disc brakes
BRAKE (REAR)
TRP, Slate T4, Hydraulic disc brakes
TUBE
Presta valve
RIM
WTB, ST i30 TCS, Double Wall
CLAMPING RING
Internal hexagon, 38.1 mm
REAR DERAILLEUR
Sram, SX Eagle
SHIFT LEVER
Sram, SX Eagle, Trigger switch
BOTTOM BRACKET
integrated in the motor
SPROCKET
Sram, Eagle PG1210, 11 - 50 teeth
CHAIN
Sram, SX Eagle
CHAINRING
Sram, 38 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
TRP, Slate T4, Aluminium
BRAKE DISC (FRONT)
Tektro, TR203, 203 mm
BRAKE DISC (REAR)
Tektro, TR203, 203 mm
TYRE
Maxxis, Minion DHF II, 63-622, 29 x 2.5 inch
FRONT WHEEL HUB
Haibike Components, The Hub ++, 6-bolt standard
REAR WHEEL HUB
Haibike Components, TheHub ++ Thru axle 12x148, 6-bolt standard
SPOKES
Sapim, Race
HANDLEBAR
Haibike Components, TheBar +++, 780 mm
GRIPS
Haibike, MTB grips
STEM
Haibike Components, TheStem +++, 31.8 mm
HEADSET
Acros, BlockLock, Aluminium
SADDLE
Selle Royal, Vivo
SEAT POST
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
PEDALS
Freeridepedal, Aluminium, with Reflector
PERMITTED TOTAL WEIGHT
150.0 kg
TYRE (REAR)
Maxxis, Minion DHR II, 66-584, 27.5 x 2.6 inch
RIM (REAR)
WTB, ST i35 TCS, Double Wall
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2999,00 [pseudoprice] => 5399,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2999 [pseudoprice_numeric] => 5399 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11111 [position] => [source] => https://www.sportgardena.com/media/image/0c/ca/a0/allmtn-2-grey-lemon.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1206 [height] => 680 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/e6/db/49/allmtn-2-grey-lemon_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/ee/74/02/allmtn-2-grey-lemon_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/e6/db/49/allmtn-2-grey-lemon_200x200.jpg, https://www.sportgardena.com/media/image/ee/74/02/allmtn-2-grey-lemon_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/g0/ce/7a/allmtn-2-grey-lemon_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/9f/32/e8/allmtn-2-grey-lemon_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/g0/ce/7a/allmtn-2-grey-lemon_600x600.jpg, https://www.sportgardena.com/media/image/9f/32/e8/allmtn-2-grey-lemon_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/7e/eb/fd/allmtn-2-grey-lemon_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/f6/96/29/allmtn-2-grey-lemon_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/7e/eb/fd/allmtn-2-grey-lemon_1280x1280.jpg, https://www.sportgardena.com/media/image/f6/96/29/allmtn-2-grey-lemon_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 8573 [imageID] => 133805 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3239,40 [pseudoprice] => 5399,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 40 [float] => 40 ) [has_pseudoprice] => 1 [price_numeric] => 3239.4 [pseudoprice_numeric] => 5399 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=SG10469 [linkDetails] => shopware.php?sViewport=detail&sArticle=3057 [linkVariant] => shopware.php?sViewport=detail&sArticle=3057&number=SG10469 ) 1The Ultra is also equipped with the Shimano XT Di2 shifting group with 12-speed transmission in the rear derailleur, which with the materials used, titanium and carbon, represents an optimal symbiosis of weight and finish. The Shimano XTR 4-piston disc brakes with Fin Pad pads and 203 mm Ice Tex brake discs ensure optimum braking distance and safety in almost all riding conditions.
Visually, the R.X735 Ultra is easily recognisable by the golden Kashima coating on the Fox 36 Factory suspension fork and the attractive frame design. With the flat steering angle of 65.5 degrees, the bike gives the rider the stability and security he or she needs for sporting challenges. Downhill with speed or uphill with power? With its 150 millimetres of suspension travel, the bike easily swallows larger roots, stones, steps, blocked passages and stairs.
The riding experience can be personalised via the special E-Tube software. The APP for mobile devices from Shimano offers two setups.
DETAILS
- Frame: Full carbon made from high modulus carbon fibres, handmade
- Fork: 150 mm travel / 110x15 mm / 44 mm offset
- Shock: 144 mm travel / 210x52.5 mm / 21.84 mm (bushing f.) / 19.05 mm (bushing r.)
- Tire front: max. 29x2.6 (755x65)
- Tire diameter rear: max. 29x2.6 (755x65)
- Permissible total weight: 130 kg / ASTM 4
- Motor: Shimano EP801 / 2 riding profiles / up to 85 Nm torque
- Battery: IPU735 / 720 Wh / 3.6 kg / Carbon / Quick Release / 4.5 A charger
- Headset with Blocklock
Battery
IPU735 QR Carbon
CAN / Removable / 720 Wh / 3,6 kg
Brake
SHIMANO XTR 9120
Fin Pad
Brake discs
SHIMANO RT900/910
Sensor ICE 203/203
Cassette
SHIMANO XTR 9100
10-51 T. / 12-Speed
Chain
SHIMANO HG 7100
12-Speed
Chain guide
e*thirteen TRS
Chainring
e*thirteen Direct Mount Chainring
34 t.
Charger
4,5 A Charger
Crank
e*thirteen Race Carbon
160 mm (S) / 165 mm (M, L) / 170 mm (XL)
Damper
Fox Float X Factory Kashima
210 x 52,5 mm / 3-Pos Adjust
Display
Shimano EM800
Drive
SHIMANO EP801
Fork
Fox 36 Float Factory Kashima
150 mm / Fit 4 3-POS Adjust / E-Tuned
Gear lever
SHIMANO XT Di2 8150
Handlebar
e*thirteen Race Carbon
Ø35 mm / 20 mm Rise / 780 mm Width / I.C.R
Handles
ERGON GD10
Slim Factory Frozen
Headset
ACROS RW735 1.5 Headset
W/ Blocklock
Rear derailleur
SHIMANO XT Di2 8150 SGS HYPERGLIDE+
Saddle
ERGON SM30 PRO
/ Ergon SM Pro
Seat post
Eightpins NGS 2
Ø34.9 mm / 25 mm Offset / 170 mm (S) / 190 mm (M) / 210 mm (L) / 230 mm (XL)
Stem
e*thirteen Plus
Ø35 mm/ 50 mm/ AL7050 I.C.R.
Wheels
Crankbrothers Synthesis Enduro I9
(31,5/29,5) / 110-15/148-12 TAS / CL
Tyres
SCHWALBE Magic Mary / Hans Dampf
EVO Super Ground / Trail TLE Soft 29 x 2.40
Negozio online e rivenditore specializzato Rotwild in Alto Adige, Italia
Sport Gardena è rivenditore specializzato Rotwild e partner di assistenza Rotwild in Alto Adige, Italia. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 38 [supplierID] => 47 [dato_easy_id] => 245 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 10999,00 [pseudoprice] => 12999,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 10999 [pseudoprice_numeric] => 12999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 16208 [position] => [source] => https://www.sportgardena.com/media/image/78/07/3f/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 2883 [height] => 1632 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/82/58/56/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/c2/39/af/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/82/58/56/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_200x200.jpg, https://www.sportgardena.com/media/image/c2/39/af/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/49/81/ee/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/41/9d/af/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/49/81/ee/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_600x600.jpg, https://www.sportgardena.com/media/image/41/9d/af/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/3f/45/30/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/41/b0/5a/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/3f/45/30/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_1280x1280.jpg, https://www.sportgardena.com/media/image/41/b0/5a/ROTWILD_RX735_ULTRA_REDMETALLIC_RX735F23U_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( ) [attribute] => Array ( ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 10999,00 [pseudoprice] => 12999,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 15 [float] => 15.39 ) [has_pseudoprice] => 1 [price_numeric] => 10999 [pseudoprice_numeric] => 12999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1586430201 [linkDetails] => shopware.php?sViewport=detail&sArticle=3009 [linkVariant] => shopware.php?sViewport=detail&sArticle=3009&number=T1586430201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 180mm
- Frame shape: MTB Fully
- Model name: Nduro 6
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox Domain R, Aria, 180mm
- Ammortizzatore: RockShox Super Deluxe Select, Aria
- Serie sterzo: Acros BlockLock
- Travel front: 180
- Travel rear: 180
Gear shift and brakes
- Cambio: Sram SX Eagle 12-S, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram Eagle PG1230, 11-50 denti
- Catena: Sram SX Eagle
- Brakes: TRP Slate G-Spec, Alluminio
- Leva del freno: TRP Slate G-Spec, Distanza manopole regolabile, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Schwalbe Magic Mary Evo TLE, 62-622 / Schwalbe Big Betty, 65-584
- Cerchio: WTB ST i30 TCS, Con occhielli, Cerchio a camera vuota
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 29/27.5
- Wheelhub: Haibike Components The Hub ++ through axle 15x110mm, Haibike Components TheHub ++ Steckachse 12x148
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem 2, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 574, 604, 631, 663
- Seat tube length: 410, 440, 465, 495
- Seat tube angle: 75
- Head tube length: 120, 130, 140
- Head tube angle: 63.5
- Chain stay length: 460
- Bottom bracket drop: -5
- Wheelbase: 1245, 1275, 1305, 1339
- Reach: 425, 455, 480, 510
- Stack: 644, 653, 662
- Seat tube offset: -23
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4199,00 [pseudoprice] => 5799,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 4199 [pseudoprice_numeric] => 5799 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 13558 [position] => [source] => https://www.sportgardena.com/media/image/64/20/c1/nduro-6.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1054 [height] => 585 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/26/7f/41/nduro-6_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/bc/8b/d2/nduro-6_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/26/7f/41/nduro-6_200x200.jpg, https://www.sportgardena.com/media/image/bc/8b/d2/nduro-6_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/4b/07/65/nduro-6_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/d6/ab/d1/nduro-6_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/4b/07/65/nduro-6_600x600.jpg, https://www.sportgardena.com/media/image/d6/ab/d1/nduro-6_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/23/f6/64/nduro-6_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/42/ea/e7/nduro-6_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/23/f6/64/nduro-6_1280x1280.jpg, https://www.sportgardena.com/media/image/42/ea/e7/nduro-6_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5974 [imageID] => 109270 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4199,00 [pseudoprice] => 5799,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 28 [float] => 27.59 ) [has_pseudoprice] => 1 [price_numeric] => 4199 [pseudoprice_numeric] => 5799 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1474540301 [linkDetails] => shopware.php?sViewport=detail&sArticle=2825 [linkVariant] => shopware.php?sViewport=detail&sArticle=2825&number=T1474540301 ) 1ENGINE
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY
InTube, 630 Wh
FRAME FAMILY
Haibike, HardNine Yamaha i630, Aluminium 6061
FORK
SR Suntour, XCM34 NLO DS, Steel spring/oil, Travel= 120 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
CRANK ARM
Haibike, forged, Aluminium
BRAKE (FRONT)
Tektro, M275, 180 mm, 2-piston disc brake
BRAKE (REAR)
Tektro, M275, 180 mm, 2-piston disc brake
TUBE
Presta valve
RIM
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
CLAMPING RING
Quick release, 34.9 mm
REAR DERAILLEUR
Shimano, Deore M4120
SHIFT LEVER
Shimano, Deore M4100, Trigger switch, 10 Speed
BOTTOM BRACKET
Integrated in the motor
SPROCKET
Shimano, CSM4100, 11 - 42 teeth
CHAIN
KMC, e10S
CHAINRING
Steel, 38 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
Tektro, M275, Aluminium
BRAKE DISC (FRONT)
Tektro, TR180
BRAKE DISC (REAR)
Tektro, TR180
TYRE
WTB, Ranger Comp, 65-622, 29" x 2.6"
FRONT WHEEL HUB
Haibike, Alu Nabe, 6-bolt standard
REAR WHEEL HUB
Haibike, Alu Nabe, 6-bolt standard
SPOKES
Sapim, Leader, Black
HANDLEBAR
XLC, Topflat, 740 mm
GRIPS
XLC, MTB grips
STEM
XLC, Alu, A-Head
HEADSET
Feimin, A-Head Tapered, Ball bearing
SADDLE
XLC, MTB
SEAT POST
XLC, Aluminium, Patent, 31.6 mm
PEDALS
Freeridepedal , Aluminium, with Reflector,
PERMITTED TOTAL WEIGHT
120.0 kg
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2324,25 [pseudoprice] => 3099,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2324.25 [pseudoprice_numeric] => 3099 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 13435 [position] => [source] => https://www.sportgardena.com/media/image/35/2d/b2/Haibike_MY21_HardNine_6.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1369 [height] => 746 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/af/f9/g0/Haibike_MY21_HardNine_6_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/99/19/37/Haibike_MY21_HardNine_6_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/af/f9/g0/Haibike_MY21_HardNine_6_200x200.jpg, https://www.sportgardena.com/media/image/99/19/37/Haibike_MY21_HardNine_6_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/2a/5e/84/Haibike_MY21_HardNine_6_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/33/fc/9d/Haibike_MY21_HardNine_6_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/2a/5e/84/Haibike_MY21_HardNine_6_600x600.jpg, https://www.sportgardena.com/media/image/33/fc/9d/Haibike_MY21_HardNine_6_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/93/df/cf/Haibike_MY21_HardNine_6_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/5f/64/4e/Haibike_MY21_HardNine_6_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/93/df/cf/Haibike_MY21_HardNine_6_1280x1280.jpg, https://www.sportgardena.com/media/image/5f/64/4e/Haibike_MY21_HardNine_6_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( ) [attribute] => Array ( ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2324,25 [pseudoprice] => 3099,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 25 [float] => 25 ) [has_pseudoprice] => 1 [price_numeric] => 2324.25 [pseudoprice_numeric] => 3099 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1472690301 [linkDetails] => shopware.php?sViewport=detail&sArticle=2818 [linkVariant] => shopware.php?sViewport=detail&sArticle=2818&number=T1472690301 ) 1ENGINE
Yamaha, PW-ST System, 250 Wh, 70 Nm, 25 km/h
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY
Yamaha, InTube, 630 Wh
FRAME FAMILY
Haibike, FullNine Yamaha i630, Aluminium 6061
FORK
SR Suntour, XCR34 Coil LOR, Lockout, Steel spring, 120 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
DAMPER
SR Suntour, Edge LO-R8, Air, Trunnion Mount
CRANK ARM
Haibike Components, The Crank +, Aluminium
BRAKE (FRONT)
Shimano, MT410, Hydraulic disc brakes
BRAKE (REAR)
Shimano, MT410, Hydraulic disc brakes
TUBE
Presta valve
RIM
Rodi, Tryp 30, With Eyelets, Double Wall, Aluminium
CLAMPING RING
Internal hexagon, 34.9 mm
REAR DERAILLEUR
Shimano, Deore M5100
SHIFT LEVER
Shimano, Deore M5100, Trigger switch
BOTTOM BRACKET
integrated in the motor
SPROCKET
Shimano, M5100, 11 - 51 teeth
CHAIN
KMC, X11e
CHAINRING
Steel, 36 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
Shimano, MT401, Aluminium
BRAKE DISC (FRONT)
Shimano, RT30-M, 180 mm
BRAKE DISC (REAR)
Shimano, RT30-M, 180 mm
TYRE
Continental, Trail King, 60-622, 29 x 2.4 inch
FRONT WHEEL HUB
Shimano, MT400-B, Centerlock
REAR WHEEL HUB
Shimano, MT400-B, Centerlock
SPOKES
Sapim, Leader
HANDLEBAR
Haibike Components, TheBar ++, 780 mm
GRIPS
Haibike, MTB grips
STEM
Haibike Components, TheStem ++, A-head, 31.8 mm, 7.0 degrees
HEADSET
Feimin, A-Head Tapered, Ball bearing
SADDLE
Selle Bassano, Reko R2 E-Sport
SEAT POST
Haibike Components, TheSeatpost ++, Aluminium, 31.6 mm
PEDALS
Freeridepedal, Aluminium, with Reflector
PERMITTED TOTAL WEIGHT
120.0 kg
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3499,00 [pseudoprice] => 4399,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 3499 [pseudoprice_numeric] => 4399 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 13427 [position] => [source] => https://www.sportgardena.com/media/image/39/d6/fb/Haibike-MY22-Main-image-AllTrail-4-275-green.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1290 [height] => 725 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/66/01/f7/Haibike-MY22-Main-image-AllTrail-4-275-green_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/11/a4/66/Haibike-MY22-Main-image-AllTrail-4-275-green_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/66/01/f7/Haibike-MY22-Main-image-AllTrail-4-275-green_200x200.jpg, https://www.sportgardena.com/media/image/11/a4/66/Haibike-MY22-Main-image-AllTrail-4-275-green_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/d6/6a/17/Haibike-MY22-Main-image-AllTrail-4-275-green_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/3a/af/f7/Haibike-MY22-Main-image-AllTrail-4-275-green_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/d6/6a/17/Haibike-MY22-Main-image-AllTrail-4-275-green_600x600.jpg, https://www.sportgardena.com/media/image/3a/af/f7/Haibike-MY22-Main-image-AllTrail-4-275-green_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/16/88/43/Haibike-MY22-Main-image-AllTrail-4-275-green_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/8b/12/e6/Haibike-MY22-Main-image-AllTrail-4-275-green_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/16/88/43/Haibike-MY22-Main-image-AllTrail-4-275-green_1280x1280.jpg, https://www.sportgardena.com/media/image/8b/12/e6/Haibike-MY22-Main-image-AllTrail-4-275-green_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5925 [imageID] => 108793 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3499,00 [pseudoprice] => 4399,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 20 [float] => 20.46 ) [has_pseudoprice] => 1 [price_numeric] => 3499 [pseudoprice_numeric] => 4399 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1NJMDB0101 [linkDetails] => shopware.php?sViewport=detail&sArticle=2817 [linkVariant] => shopware.php?sViewport=detail&sArticle=2817&number=T1NJMDB0101 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio 6061, 24"
- Frame shape: MTB Hardtail
- Model name: ALLTRACK Kids
- Peso totale consentito: 80
- Frame height: 34
- Forcella: SR Suntour XCR LO Lockout, Molla in acciaio, 63mm
- Serie sterzo: A-Head Tapered
- Travel front: 63
Gear shift and brakes
- Cambio: Shimano Altus M2000, 9 velocità, Altus M2010, Rapidfire
- Pacco pignoni : SunRace CSM90, 11-36 denti
- Catena: KMC X9
- Brakes: Tektro M282, 160mm / 160mm
- Leva del freno: Tektro M282, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank +
Propulsion
- Motore: Yamaha PW-TE System, 250W, 20km/h, 60Nm
- Caricabatterie: Yamaha Caricatore rapido 4A
- Batteria: Yamaha Ioni di litio 400Wh
- Battery capacity: 400
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 60
Wheels and wheel components
- Copertone: Schwalbe Billy Bonkers, 50-507
- Cerchio: Rodi FW Disc, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Leader
- Dimensione ruota: 24
- Wheelhub: Haibike Components TheHub +, Haibike Components TheHub +
Handlebar and saddle
- Sella: Haibike Components TheSaddle Kids
- Reggisella: Haibike Components The Seatpost +, Patent, 31.6 mm, Alluminio
- Manubrio: Haibike Components TheBar + Topflat, 640 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem ++, A-head, Handlebar diameter: 31.8 mm, 12˚
Geometry
- Top tube length (horizontal): 500
- Seat tube length: 340
- Seat tube angle: 73
- Head tube length: 165
- Head tube angle: 68
- Chain stay length: 415
- Bottom bracket drop: -30
- Wheelbase: 1000
- Reach: 330
- Stack: 556
- Stand-over height: 67
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2149,00 [pseudoprice] => 2699,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2149 [pseudoprice_numeric] => 2699 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 13428 [position] => [source] => https://www.sportgardena.com/media/image/fe/48/89/Haibike-MY22-Main-image-AllTrack-Kids.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1216 [height] => 770 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/7d/04/ae/Haibike-MY22-Main-image-AllTrack-Kids_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/02/0d/12/Haibike-MY22-Main-image-AllTrack-Kids_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/7d/04/ae/Haibike-MY22-Main-image-AllTrack-Kids_200x200.jpg, https://www.sportgardena.com/media/image/02/0d/12/Haibike-MY22-Main-image-AllTrack-Kids_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/70/1d/90/Haibike-MY22-Main-image-AllTrack-Kids_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/5d/2f/7d/Haibike-MY22-Main-image-AllTrack-Kids_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/70/1d/90/Haibike-MY22-Main-image-AllTrack-Kids_600x600.jpg, https://www.sportgardena.com/media/image/5d/2f/7d/Haibike-MY22-Main-image-AllTrack-Kids_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/0c/ac/a7/Haibike-MY22-Main-image-AllTrack-Kids_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/1d/4f/12/Haibike-MY22-Main-image-AllTrack-Kids_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/0c/ac/a7/Haibike-MY22-Main-image-AllTrack-Kids_1280x1280.jpg, https://www.sportgardena.com/media/image/1d/4f/12/Haibike-MY22-Main-image-AllTrack-Kids_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5927 [imageID] => 108800 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2149,00 [pseudoprice] => 2699,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 20 [float] => 20.38 ) [has_pseudoprice] => 1 [price_numeric] => 2149 [pseudoprice_numeric] => 2699 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T3B2RHR0101 [linkDetails] => shopware.php?sViewport=detail&sArticle=2786 [linkVariant] => shopware.php?sViewport=detail&sArticle=2786&number=T3B2RHR0101 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 180mm
- Frame shape: MTB Fully
- Model name: Nduro 7
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: FOX Performance 38, Aria, 180mm
- Ammortizzatore: FOX Float X2 Performance 170 mm
- Serie sterzo: Acros BlockLock
- Travel front: 180
- Travel rear: 180
Gear shift and brakes
- Cambio: Shimano SLX M7100, 12 velocità, Deore SLX M7100
- Pacco pignoni : Shimano M6100
- Catena: Shimano M6100
- Brakes: Magura MT5
- Leva del freno: Magura MT5 leva-HC, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank +++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Interface - X
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Schwalbe Magic Mary Evo TLE, 62-622 / Schwalbe Big Betty Evo Gravity, 65-584
- Tube: Valvola Presta
- Dimensione ruota: 29/27.5
- Set di ruote: Mavic E-Deemax
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem 2, A-head, Handlebar diameter: 31.8 mm
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 5199,00 [pseudoprice] => 6499,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 5199 [pseudoprice_numeric] => 6499 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11099 [position] => [source] => https://www.sportgardena.com/media/image/8a/4a/a5/nduro-7.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1472 [height] => 825 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/1f/a1/fc/nduro-7_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/12/92/18/nduro-7_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/1f/a1/fc/nduro-7_200x200.jpg, https://www.sportgardena.com/media/image/12/92/18/nduro-7_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/44/d4/c9/nduro-7_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/d8/98/bf/nduro-7_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/44/d4/c9/nduro-7_600x600.jpg, https://www.sportgardena.com/media/image/d8/98/bf/nduro-7_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/26/6e/56/nduro-7_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/73/64/c8/nduro-7_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/26/6e/56/nduro-7_1280x1280.jpg, https://www.sportgardena.com/media/image/73/64/c8/nduro-7_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( ) [attribute] => Array ( ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 5199,00 [pseudoprice] => 6499,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 20 [float] => 20 ) [has_pseudoprice] => 1 [price_numeric] => 5199 [pseudoprice_numeric] => 6499 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1296350201 [linkDetails] => shopware.php?sViewport=detail&sArticle=2249 [linkVariant] => shopware.php?sViewport=detail&sArticle=2249&number=T1296350201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Carbon/Aluminum, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn CF 9
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox Yari RC, Aria, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: Acros Cable integration
- Travel front: 160
- Travel rear: 150, 160
Gear shift and brakes
- Cambio: Sram NX Eagle, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram PG1210 11-50T
- Catena: Sram SX Eagle
- Brakes: Shimano MT420, Alluminio, 203mm / 203mm
- Leva del freno: Shimano MT401, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX Smart System, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch
- Batteria: Bosch PowerTube 750Wh
- Battery capacity: 750
- Display: Bosch Kiox 300 + LED Remote
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 65-622 / Maxxis Minion DHR II, 71-584
- Cerchio: Rodi Tryp 30, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Leader
- Dimensione ruota: 29/27.5
- Wheelhub: Shimano MT400-B, Shimano MT400-B
Handlebar and saddle
- Sella: fi'zi:k Terra Aidon X5-160
- Reggisella: dropper-post remote, Telescopico, 31.6 mm, Alluminio
- Manubrio: Haibike Components TheBar ++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Alluminio, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 577, 606, 642, 676
- Seat tube length: 410, 440, 470, 500
- Seat tube angle: 76
- Head tube length: 100, 110, 120, 130
- Head tube angle: 64.1
- Chain stay length: 455
- Bottom bracket drop: 23
- Wheelbase: 1191, 1230, 1267, 1303
- Reach: 403, 435, 463, 496
- Stack: 629, 638, 647, 657
- Seat tube offset: 15
- Stand-over height: 79, 81, 83
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 5099,00 [pseudoprice] => 6799,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 5099 [pseudoprice_numeric] => 6799 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 16629 [position] => [source] => https://www.sportgardena.com/media/image/54/18/55/Haibike-MY22-Main-image-AllMtn-CF-9-blue.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1288 [height] => 740 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/49/8a/d9/Haibike-MY22-Main-image-AllMtn-CF-9-blue_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/83/88/10/Haibike-MY22-Main-image-AllMtn-CF-9-blue_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/49/8a/d9/Haibike-MY22-Main-image-AllMtn-CF-9-blue_200x200.jpg, https://www.sportgardena.com/media/image/83/88/10/Haibike-MY22-Main-image-AllMtn-CF-9-blue_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/0a/71/70/Haibike-MY22-Main-image-AllMtn-CF-9-blue_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/ae/e9/c0/Haibike-MY22-Main-image-AllMtn-CF-9-blue_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/0a/71/70/Haibike-MY22-Main-image-AllMtn-CF-9-blue_600x600.jpg, https://www.sportgardena.com/media/image/ae/e9/c0/Haibike-MY22-Main-image-AllMtn-CF-9-blue_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/15/6d/cb/Haibike-MY22-Main-image-AllMtn-CF-9-blue_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/a8/33/27/Haibike-MY22-Main-image-AllMtn-CF-9-blue_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/15/6d/cb/Haibike-MY22-Main-image-AllMtn-CF-9-blue_1280x1280.jpg, https://www.sportgardena.com/media/image/a8/33/27/Haibike-MY22-Main-image-AllMtn-CF-9-blue_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 8831 [imageID] => 136158 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 5099,00 [pseudoprice] => 6799,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 25 [float] => 25 ) [has_pseudoprice] => 1 [price_numeric] => 5099 [pseudoprice_numeric] => 6799 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295930201 [linkDetails] => shopware.php?sViewport=detail&sArticle=2244 [linkVariant] => shopware.php?sViewport=detail&sArticle=2244&number=T1295930201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Carbon/Aluminum, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn CF 8
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox 35 Gold RL, Aria, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: Acros Cable integration
- Travel front: 160
- Travel rear: 150, 160
Gear shift and brakes
- Cambio: Sram SX Eagle 12-S, 12 velocità, SX Eagle, Comando Trigger
- Pacco pignoni : Sram PG1210 11-50T
- Catena: Sram SX Eagle
- Brakes: Shimano MT420, Alluminio, 203mm / 203mm
- Leva del freno: Shimano MT401, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX Smart System, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch
- Batteria: Bosch PowerTube 750Wh
- Battery capacity: 750
- Display: Bosch Kiox 300 + LED Remote
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 65-622 / Maxxis Minion DHR II, 71-584
- Cerchio: Rodi Tryp 30, Con occhielli, Cerchio a camera vuota, Alluminio
- Tube: Valvola Presta
- Raggi: Sapim Leader
- Dimensione ruota: 29/27.5
- Wheelhub: Shimano MT400-B, Shimano MT400-B
Handlebar and saddle
- Sella: fi'zi:k Terra Aidon X5-160
- Reggisella: dropper-post remote, Telescopico, 31.6 mm, Alluminio
- Manubrio: Haibike Components TheBar ++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Alluminio, A-head, Handlebar diameter: 31.8 mm
Geometry
- Top tube length (horizontal): 577, 606, 642, 676
- Seat tube length: 410, 440, 470, 500
- Seat tube angle: 76
- Head tube length: 100, 110, 120, 130
- Head tube angle: 64.1
- Chain stay length: 455
- Bottom bracket drop: 23
- Wheelbase: 1191, 1230, 1267, 1303
- Reach: 403, 435, 463, 496
- Stack: 629, 638, 647, 657
- Seat tube offset: 15
- Stand-over height: 79, 81, 83
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4499,00 [pseudoprice] => 6299,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 4499 [pseudoprice_numeric] => 6299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11105 [position] => [source] => https://www.sportgardena.com/media/image/3c/97/65/allmtn-cf-8.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1206 [height] => 670 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/d0/17/3b/allmtn-cf-8_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/5d/69/4b/allmtn-cf-8_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/d0/17/3b/allmtn-cf-8_200x200.jpg, https://www.sportgardena.com/media/image/5d/69/4b/allmtn-cf-8_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/f4/31/a3/allmtn-cf-8_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/ea/e6/8c/allmtn-cf-8_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/f4/31/a3/allmtn-cf-8_600x600.jpg, https://www.sportgardena.com/media/image/ea/e6/8c/allmtn-cf-8_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/6b/32/31/allmtn-cf-8_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/ea/89/4b/allmtn-cf-8_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/6b/32/31/allmtn-cf-8_1280x1280.jpg, https://www.sportgardena.com/media/image/ea/89/4b/allmtn-cf-8_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5965 [imageID] => 109319 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4499,00 [pseudoprice] => 6299,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 29 [float] => 28.58 ) [has_pseudoprice] => 1 [price_numeric] => 4499 [pseudoprice_numeric] => 6299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295880201 [linkDetails] => shopware.php?sViewport=detail&sArticle=2243 [linkVariant] => shopware.php?sViewport=detail&sArticle=2243&number=T1295880201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Carbon/Aluminum, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn CF 11
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox Lyrik Select RC, Aria/Olio, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: Acros Cable integration
- Travel front: 160
- Travel rear: 150, 160
Gear shift and brakes
- Cambio: Shimano Deore XT RD-M8100 12-S, 12 velocità, Deore SLX M7100
- Pacco pignoni : Shimano M6100
- Catena: Shimano M6100
- Brakes: Magura MT5
- Leva del freno: Magura MT5 leva-HC, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Bosch Performance CX Smart System, 250W, 25km/h, 85Nm
- Caricabatterie: Bosch
- Batteria: Bosch PowerTube 750Wh
- Battery capacity: 750
- Display: Bosch Kiox 300 + LED Remote
- Engine manufacturer: Bosch
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 65-622 / Maxxis Minion DHR II, 71-584
- Tube: Valvola Presta
- Dimensione ruota: 29/27.5
- Set di ruote: DT Swiss H1900
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4999,00 [pseudoprice] => 7499,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 4999 [pseudoprice_numeric] => 7499 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11106 [position] => [source] => https://www.sportgardena.com/media/image/86/ab/bd/allmtn-cf-11.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1206 [height] => 668 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/41/e8/83/allmtn-cf-11_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/d7/f2/d0/allmtn-cf-11_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/41/e8/83/allmtn-cf-11_200x200.jpg, https://www.sportgardena.com/media/image/d7/f2/d0/allmtn-cf-11_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/27/31/3a/allmtn-cf-11_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/61/b7/f9/allmtn-cf-11_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/27/31/3a/allmtn-cf-11_600x600.jpg, https://www.sportgardena.com/media/image/61/b7/f9/allmtn-cf-11_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/e4/18/bf/allmtn-cf-11_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/c3/ca/34/allmtn-cf-11_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/e4/18/bf/allmtn-cf-11_1280x1280.jpg, https://www.sportgardena.com/media/image/c3/ca/34/allmtn-cf-11_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5966 [imageID] => 109324 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4999,00 [pseudoprice] => 7499,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 33 [float] => 33.34 ) [has_pseudoprice] => 1 [price_numeric] => 4999 [pseudoprice_numeric] => 7499 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295780201 [linkDetails] => shopware.php?sViewport=detail&sArticle=2241 [linkVariant] => shopware.php?sViewport=detail&sArticle=2241&number=T1295780201 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn 7
- Peso totale consentito: 150
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: FOX 36 Float Performance Luft 160 Lockout, Aria, 160mm
- Ammortizzatore: FOX Float DPS Performance EVOL LV Trunnion, Aria
- Serie sterzo: Acros BlockLock
- Travel front: 160
- Travel rear: 160
Gear shift and brakes
- Cambio: Sram GX Eagle Transmission 12-S, 12 velocità, GX Eagle, Comando Trigger
- Pacco pignoni : Sram Eagle PG1230, 11-50 denti
- Catena: Sram SX Eagle
- Brakes: Magura MT7, 203mm / 203mm
- Leva del freno: Magura MT7 leva-HC, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Interface - X
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584
- Cerchio: WTB ST i30 TCS, Con occhielli, Cerchio a camera vuota
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 29/27.5
- Wheelhub: Haibike Components The Hub ++ through axle 15x110mm, Haibike Components TheHub ++ Steckachse 12x148
Handlebar and saddle
- Sella: fi'zi:k Terra Aidon X5-160
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem +++
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4949,00 [pseudoprice] => 6599,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 4949 [pseudoprice_numeric] => 6599 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11108 [position] => [source] => https://www.sportgardena.com/media/image/f3/5c/e1/allmtn-7-red.jpg [description] => [extension] => jpg [main] => [parentId] => [width] => 1206 [height] => 676 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/3f/f1/cb/allmtn-7-red_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/d6/e1/56/allmtn-7-red_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/3f/f1/cb/allmtn-7-red_200x200.jpg, https://www.sportgardena.com/media/image/d6/e1/56/allmtn-7-red_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/44/f7/5d/allmtn-7-red_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/e2/be/95/allmtn-7-red_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/44/f7/5d/allmtn-7-red_600x600.jpg, https://www.sportgardena.com/media/image/e2/be/95/allmtn-7-red_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/d1/90/b5/allmtn-7-red_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/26/3f/f7/allmtn-7-red_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/d1/90/b5/allmtn-7-red_1280x1280.jpg, https://www.sportgardena.com/media/image/26/3f/f7/allmtn-7-red_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 8283 [imageID] => 129568 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 4949,00 [pseudoprice] => 6599,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 25 [float] => 25 ) [has_pseudoprice] => 1 [price_numeric] => 4949 [pseudoprice_numeric] => 6599 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295730302 [linkDetails] => shopware.php?sViewport=detail&sArticle=2240 [linkVariant] => shopware.php?sViewport=detail&sArticle=2240&number=T1295730302 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn 4
- Peso totale consentito: 135
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: RockShox Yari RC, Aria, 160mm
- Ammortizzatore: RockShox Deluxe Select Plus, Aria
- Serie sterzo: Acros BlockLock
- Travel front: 160
- Travel rear: 160
Gear shift and brakes
- Cambio: Shimano SLX M7100, 12 velocità, Deore SLX M7100
- Pacco pignoni : Shimano M6100
- Catena: Shimano M6100
- Brakes: Shimano Deore M6120, Alluminio, 203mm / 203mm
- Leva del freno: Shimano Deore M6100, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Side Switch
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584
- Cerchio: WTB ST i30 TCS, Con occhielli, Cerchio a camera vuota
- Tube: Valvola Presta
- Raggi: Sapim Race
- Dimensione ruota: 29/27.5
- Wheelhub: Shimano MT410-B, Shimano MT410-B
Handlebar and saddle
- Sella: Selle Royal Vivo
- Reggisella: Dropper-Post Remote, Telescopico, 34.9 mm, Alluminio
- Manubrio: Haibike Components TheBar +++, 780 mm
- Manopole: Haibike Manopole MTB
- Attacco manubrio: Haibike Components TheStem +++
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3999,00 [pseudoprice] => 5999,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 3999 [pseudoprice_numeric] => 5999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11109 [position] => [source] => https://www.sportgardena.com/media/image/c9/54/17/allmtn-4-22.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1204 [height] => 680 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/bd/35/5d/allmtn-4-22_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/da/9a/b6/allmtn-4-22_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/bd/35/5d/allmtn-4-22_200x200.jpg, https://www.sportgardena.com/media/image/da/9a/b6/allmtn-4-22_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/c7/31/38/allmtn-4-22_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/29/e1/42/allmtn-4-22_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/c7/31/38/allmtn-4-22_600x600.jpg, https://www.sportgardena.com/media/image/29/e1/42/allmtn-4-22_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/c2/27/45/allmtn-4-22_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/f9/e9/13/allmtn-4-22_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/c2/27/45/allmtn-4-22_1280x1280.jpg, https://www.sportgardena.com/media/image/f9/e9/13/allmtn-4-22_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5969 [imageID] => 109339 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 3999,00 [pseudoprice] => 5999,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 33 [float] => 33.34 ) [has_pseudoprice] => 1 [price_numeric] => 3999 [pseudoprice_numeric] => 5999 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295680401 [linkDetails] => shopware.php?sViewport=detail&sArticle=2239 [linkVariant] => shopware.php?sViewport=detail&sArticle=2239&number=T1295680401 ) 1Frame and more
- Brand: Haibike
- Telaio: Haibike Alluminio, 29", 160mm
- Frame shape: MTB Fully
- Model name: AllMtn 10
- Peso totale consentito: 120
- Frame height:
- · 41
- · 44
- · 47
- · 50
- Forcella: FOX 38 Factory Kashima, Aria, 160mm
- Ammortizzatore: FOX Float X Factory EVOL LV, Aria
- Serie sterzo: Acros BlockLock
- Travel front: 160
- Travel rear: 160
Gear shift and brakes
- Cambio: Shimano Deore XT RD-M8100 12-S, 12 velocità, Deore XT M8100, Comando Trigger
- Pacco pignoni : Shimano M6100
- Catena: Shimano SLX M7100
- Brakes: Shimano Deore XT M8120, 203mm / 203mm
- Leva del freno: Shimano Deore XT M8100, Alluminio
- Guidacatena: Nylon montaggio diretto
- Crank arm: Haibike Components The Crank ++
Propulsion
- Motore: Yamaha PW-X3, 250W, 25km/h, 85Nm
- Caricabatterie: Fast Charger 4A
- Batteria: InTube 720Wh
- Battery capacity: 720
- Display: Yamaha Interface - X
- Engine manufacturer: Yamaha
- Engine torque: 85
Wheels and wheel components
- Copertone: Maxxis Minion DHF, 63-622 / Maxxis Minion DHR II, 66-584
- Tube: Valvola Presta
- Dimensione ruota: 29/27.5
- Set di ruote: Mavic E-Deemax
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 5499,00 [pseudoprice] => 7299,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 5499 [pseudoprice_numeric] => 7299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 11113 [position] => [source] => https://www.sportgardena.com/media/image/00/7e/5f/allmtn-10-22.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1203 [height] => 676 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/7c/69/49/allmtn-10-22_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/aa/f5/a8/allmtn-10-22_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/7c/69/49/allmtn-10-22_200x200.jpg, https://www.sportgardena.com/media/image/aa/f5/a8/allmtn-10-22_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/2f/ab/a3/allmtn-10-22_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/59/71/df/allmtn-10-22_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/2f/ab/a3/allmtn-10-22_600x600.jpg, https://www.sportgardena.com/media/image/59/71/df/allmtn-10-22_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/a5/35/51/allmtn-10-22_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/de/fc/27/allmtn-10-22_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/a5/35/51/allmtn-10-22_1280x1280.jpg, https://www.sportgardena.com/media/image/de/fc/27/allmtn-10-22_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( ) [attribute] => Array ( ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 5499,00 [pseudoprice] => 7299,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 25 [float] => 24.66 ) [has_pseudoprice] => 1 [price_numeric] => 5499 [pseudoprice_numeric] => 7299 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1295450201 [linkDetails] => shopware.php?sViewport=detail&sArticle=2236 [linkVariant] => shopware.php?sViewport=detail&sArticle=2236&number=T1295450201 ) 1Specifiche
ENGINE
Yamaha, PW-ST System, 250W, 70 Nm, 25 km/h
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY
InTube, 630 Wh
FRAME FAMILY
Haibike, HardSeven Yamaha i630, Aluminium 6061
FORK
SR Suntour, XCM34 NLO DS, Steel spring/oil, Travel= 120 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
CRANK ARM
Haibike, forged, Aluminium
BRAKE (FRONT)
Tektro, M275, 180 mm, 2-piston disc brake
BRAKE (REAR)
Tektro, M275, 180 mm, 2-piston disc brake
TUBE
Presta valve
RIM
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
CLAMPING RING
Quick release, 34.9 mm
REAR DERAILLEUR
Shimano, Deore M4120
SHIFT LEVER
Shimano, Deore M4100, Trigger switch, 10 Speed
BOTTOM BRACKET
Integrated in the motor
SPROCKET
Shimano, CSM4100, 11 - 42 teeth
CHAIN
KMC, e10S
CHAINRING
Steel, 38 teeth
CHAIN GUIDE
Nylon directmount
BRAKE LEVER
Tektro, M275, Aluminium
BRAKE DISC (FRONT)
Tektro, TR180
BRAKE DISC (REAR)
Tektro, TR180
TYRE
WTB, Ranger Comp, 65-584, 27.5" x 2.6"
FRONT WHEEL HUB
Haibike, Alu Nabe, 6-bolt standard
REAR WHEEL HUB
Haibike, Alu Nabe, 6-bolt standard
SPOKES
Sapim, Leader, Black
HANDLEBAR
XLC, Topflat, 740 mm
GRIPS
XLC, MTB grips
STEM
XLC, Alu, A-Head
HEADSET
Feimin, A-Head Tapered, Ball bearing
SADDLE
XLC, MTB
SEAT POST
XLC, Aluminium, Patent, 31.6 mm
PEDALS
Freeridepedal , Aluminium, with Reflector,
PERMITTED TOTAL WEIGHT
120.0 kg
Negozio online e rivenditori specializzato Haibike in Alto Adige
Sport Gardena è rivenditore specializzato Haibike e partner di assistenza Haibike in Alto Adige. Acquista la tua mountain bike elettrica nel nostro negozio online o direttamente nel negozio in loco. Contattaci per un consiglio di acquisto senza impegno.
[supplier_attributes] => Array ( [core] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 11 [supplierID] => 2 [dato_easy_id] => 200000011 [hidden_in_subshop] => [is_highlighted] => 0 [alternative_url] => ) ) ) [newArticle] => [sUpcoming] => [topseller] => [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2324,25 [pseudoprice] => 3099,00 [referenceprice] => 0 [has_pseudoprice] => 1 [price_numeric] => 2324.25 [pseudoprice_numeric] => 3099 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) [image] => Array ( [id] => 9393 [position] => [source] => https://www.sportgardena.com/media/image/c6/64/f3/Haibike-HardSeven-6-grau.jpg [description] => [extension] => jpg [main] => 1 [parentId] => [width] => 1215 [height] => 669 [thumbnails] => Array ( [0] => Array ( [source] => https://www.sportgardena.com/media/image/06/0e/91/Haibike-HardSeven-6-grau_200x200.jpg [retinaSource] => https://www.sportgardena.com/media/image/fd/76/12/Haibike-HardSeven-6-grau_200x200@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/06/0e/91/Haibike-HardSeven-6-grau_200x200.jpg, https://www.sportgardena.com/media/image/fd/76/12/Haibike-HardSeven-6-grau_200x200@2x.jpg 2x [maxWidth] => 200 [maxHeight] => 200 [attributes] => Array ( ) ) [1] => Array ( [source] => https://www.sportgardena.com/media/image/8a/0e/7c/Haibike-HardSeven-6-grau_600x600.jpg [retinaSource] => https://www.sportgardena.com/media/image/68/af/43/Haibike-HardSeven-6-grau_600x600@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/8a/0e/7c/Haibike-HardSeven-6-grau_600x600.jpg, https://www.sportgardena.com/media/image/68/af/43/Haibike-HardSeven-6-grau_600x600@2x.jpg 2x [maxWidth] => 600 [maxHeight] => 600 [attributes] => Array ( ) ) [2] => Array ( [source] => https://www.sportgardena.com/media/image/78/23/fe/Haibike-HardSeven-6-grau_1280x1280.jpg [retinaSource] => https://www.sportgardena.com/media/image/99/0f/91/Haibike-HardSeven-6-grau_1280x1280@2x.jpg [sourceSet] => https://www.sportgardena.com/media/image/78/23/fe/Haibike-HardSeven-6-grau_1280x1280.jpg, https://www.sportgardena.com/media/image/99/0f/91/Haibike-HardSeven-6-grau_1280x1280@2x.jpg 2x [maxWidth] => 1280 [maxHeight] => 1280 [attributes] => Array ( ) ) ) [attributes] => Array ( [image] => Shopware\Bundle\StoreFrontBundle\Struct\Attribute Object ( [storage:protected] => Array ( [id] => 5958 [imageID] => 109275 [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) ) [attribute] => Array ( [attribute1] => [attribute2] => [attribute3] => [kib_variantlisting_prop_img_mapping] => ) ) [prices] => Array ( [0] => Array ( [valFrom] => 1 [valTo] => [from] => 1 [to] => [price] => 2324,25 [pseudoprice] => 3099,00 [referenceprice] => 0 [pseudopricePercent] => Array ( [int] => 25 [float] => 25 ) [has_pseudoprice] => 1 [price_numeric] => 2324.25 [pseudoprice_numeric] => 3099 [price_attributes] => Array ( ) [pricegroup] => EK [minpurchase] => 1 [maxpurchase] => 1 [purchasesteps] => 1 [purchaseunit] => [referenceunit] => [packunit] => [unitID] => [sUnit] => Array ( [unit] => [description] => ) [unit_attributes] => Array ( ) ) ) [linkBasket] => shopware.php?sViewport=basket&sAdd=T1211280201 [linkDetails] => shopware.php?sViewport=detail&sArticle=1930 [linkVariant] => shopware.php?sViewport=detail&sArticle=1930&number=T1211280201 ) 1
